| PartNumber | LQ9D011 |
| Znamka | SHARP |
| Velikost | 8.4 |
| Aplikacija | IA |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 70 |
| CR | 60:1 |
| Barve | 512 |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LQ9D011 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.4 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 170.88×129.6 mm |
| oris | 243.5×180 mm |
| površino | Antiglare, Hard coating (2H) |
| svetlost | 70 cd/m² (Typ.) |
| kontrastno razmerje | 60:1 (Typ.) |
| barve zaslona | 512 (3-bit) |
| odzivni čas | 30/50 (Typ.)(Tr/Td) |
| vidni kot | 45/45/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 3-bit), 21 pins |
| vhodna napetost | 5.0V (Typ.)(VCC) |
| aplikacija | IA |
