| PartNumber | LQ173D1JW33 |
| Znamka | Sharp |
| Velikost | 17.3 |
| Aplikacija | Laptop |
| Resolucija | 3840×2160 |
| Sestava | Oxide TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | Sharp |
| velikost plošče | 17.3" |
| resolucija | 3840(RGB)×2160, UHD, 255PPI |
| prikazno območje | 382.12(W)×214.94(H) mm |
| velikost obrisa | 393.69(W)×252.1(H) ×4(D) mm |
| svetlost | 350 cd/m² (Typ.) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 100% Adobe RGB |
| pogostost | 60Hz |
| slog oblike | Flat (PCBA Flat, T3.4~4.0mm) |
| signalni vmesnik | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | LQ173D1JW33 (SHP145A) |
| vrsta plošče | Oxide TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare (Haze 45%), Hard coating (3H) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | IPS, Normally Black, Transmissive |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| tip svetilke | WLED , 12K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Laptop |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| LP173WD1-TLA2 | LG Display | 17.3 | 1600×900 |
| LP173WF1-TLB2 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LP173WF1-TLC1 | LG Display | 17.3 | 1920×1080 |
| LTN173KT01-H01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W01 | Samsung | 17.3 | 1600×900 |
