| PartNumber | LQ080M1SX01 |
| Znamka | Sharp |
| Velikost | 8.0 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1200×1920 |
| Sestava | Oxide TFT-LCD , LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 5S5P |
| Vmesnik | |
| znamka plošče | Sharp |
| velikost plošče | 8.0" |
| resolucija | 1200(RGB)×1920, WUXGA, 284PPI |
| prikazno območje | 107.28(W)×171.648(H) mm |
| velikost obrisa | 112.38(W)×182.75(H) ×3.19(D) mm |
| svetlost | 500 cd/m² (Typ.) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 90% NTSC |
| pogostost | 75Hz |
| utež | 67g (Max.) |
| panelni model | LQ080M1SX01 |
| vrsta plošče | Oxide TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Clear, Hard coating |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| način prikaza | IPS, Normally Black, Transmissive |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| tip svetilke | 5S5P WLED , 15K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Pad & Tablet |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5CGQ1 | SHARP | 8.0 | 800×480 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DR01 | SHARP | 8.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
