| PartNumber | LQ039Q2DS51 |
| Znamka | SHARP |
| Velikost | 3.9 |
| Aplikacija | HHP |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 65 |
| CR | |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LQ039Q2DS51 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.9 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Reflective |
| aktivno območje | 79.2×58.32 mm |
| oris | 104.5×79.6 mm |
| površino | Hard coating (3H) |
| svetlost | 65 cd/m² (Typ.) |
| kontrastno razmerje | 5.5/4.5(Reflective) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 30/50 (Typ.)(Tr/Td) |
| vidni kot | 40/40/35/35 (Typ.)(CR≥2)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 50 pins |
| vhodna napetost | 5.0/3.3/15.0/-15.0V (Typ.)(VSHA/VSHD/VDD/VSS) |
| aplikacija | HHP |
| LQ039Q2DS51 | SHARP | 3.9 | 320×240 |
| 24QVF1H | SII | 2.4 | 240×320 |
| 30WQF0H | SII | 3.0 | 240×400 |
| 32WVF0H | SII | 3.2 | 480×800 |
| DLC0200EUG | Other | 2.0 | 240×320 |
| LH300Q01-ED01 | LG Display | 3.0 | 320×240 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LS037V7DW02 | SHARP | 3.7 | 480×640 |
| LS037V7DW06 | SHARP | 3.7 | 480×640 |
| LTM035A776C | TOSHIBA | 3.5 | 240×320 |
