| PartNumber | LP125WH2-SPR1 |
| Znamka | LG Display |
| Velikost | 12.5 |
| Aplikacija | PAD |
| Resolucija | 1366×768 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | LG Display |
| panelni model | LP125WH2-SPR1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 12.5 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | AH-IPS, Normally Black, Transmissive |
| aktivno območje | 275.59×154.94 mm |
| površino | |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Min.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | eDP (1 Lane) |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
