| PartNumber | HE101NA-02C |
| Znamka | Innolux |
| Velikost | 10.1 |
| Aplikacija | PAD |
| Resolucija | 1280×800 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | TTL |
| znamka plošče | CHIMEI INNOLUX |
| panelni model | HE101NA-02C |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 10.1 inch |
| resolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 216.96×135.6 mm |
| oris | 224.21×145×1.43 mm |
| površino | Glare (Haze 0%) |
| globina stekla | 0.50+0.50 mm |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 10/20 (Typ.)(Tr/Td) |
| vidni kot | 75/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikacija | PAD |
