| PartNumber | LM230WF9-SSA1 |
| Znamka | LG Display |
| Velikost | 23.0 |
| Aplikacija | Desktop Monitor |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | LG Display |
| model | LM230WF9-SSA1 |
| velikost diagonale | 23.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1920(RGB)×1080 [FHD] 95PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 509.184(H)×286.416(V) mm |
| obris dim. | 516.984(H)×302.708(V) ×14.2(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 14 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | WLED [14S4P] , 30K hours , W/O Driver |
| utež | 1.79/1.88Kgs (Typ./Max.) |
| namenjen za | Desktop Monitor |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
