| PartNumber | LM116LF3L02 |
| Znamka | PANDA |
| Velikost | 11.6 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1920×1080 |
| Sestava | LCM , Oxide TFT-LC |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| proizvajalec | PANDA |
| ime modela | LM116LF3L02 (NCP0000) |
| velikost zaslona | 11.6 inch |
| vrsto zaslona | LCM , Oxide TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 190PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 256.32 × 144.18 (H×V) |
| obris (mm) | 268 × 168 × 3 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | FFS, Normally Black, Transmissive |
| barvna globina | 16.7M 100% sRGB |
| osvetlitev ozadja | WLED , 15K hours , With LED Driver |
| masa | 215g (Max.) |
| uporablja za | Pad & Tablet |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
