| PartNumber | LH480HX1-SD01 |
| Znamka | LG Display |
| Velikost | 4.8 |
| Aplikacija | MPH |
| Resolucija | 480×1024 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 700:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | LG Display |
| panelni model | LH480HX1-SD01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 4.8 inch |
| resolucija | 480(RGB)×1024 |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 51.84×110.592 mm |
| oris | 57.64×121.45 mm |
| površino | |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.2M (6-bit + Dithering), CIE193168% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 5S2PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| vhodna napetost | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikacija | MPH |
