| PartNumber | LB070WV1-TD01 |
| Znamka | LG Display |
| Velikost | 7.0 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 600 |
| CR | |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | LG.Philips LCD |
| panelni model | LB070WV1-TD01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 170×109.6×17.3 mm |
| površino | Antiglare |
| svetlost | 600 cd/m² (Min.) |
| kontrastno razmerje | |
| barve zaslona | 262K (6-bit), CIE193145% |
| odzivni čas | 10/40 (Typ.)(Tr/Td) |
| vidni kot | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.)(VCC) |
| aplikacija | CNS |
