| PartNumber | LA084X02-SL01 |
| Znamka | LG Display |
| Velikost | 8.4 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | 10S3P |
| Vmesnik | LVDS |
| proizvajalec | LG Display |
| ime modela | LA084X02-SL01 |
| velikost zaslona | 8.4 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×768 (XGA) 152PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 170.496 × 127.872 (H×V) |
| obris (mm) | 184.5 × 143 × 9.95 (H×V×D) |
| svetilnost | 1200 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10) |
| odgovor | 40 (Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS, Normally Black, Transmissive |
| barvna globina | 16.2M 70% NTSC |
| osvetlitev ozadja | 10S3P WLED , No Driver |
| masa | 255/260g (Typ./Max.) |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 8-bit) , FPC 40 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ9D01C | SHARP | 8.4 | 640×480 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
