| PartNumber | LA070WV7-SL02 |
| Znamka | LG Display |
| Velikost | 7.0 |
| Aplikacija | Outdoor High Brightn |
| Resolucija | 800×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1100:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S3P |
| Vmesnik | LVDS |
| proizvajalec | LG Display |
| ime modela | LA070WV7-SL02 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| obris (mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| površina okvirja (mm) | 158.4 × 94.2 (H×V) |
| zdravljenje | Antiglare (Haze 25%) |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1100 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 16/14 (Typ.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS, Normally Black, Transmissive |
| barvna globina | 16.7M 65% NTSC |
| osvetlitev ozadja | 6S3P WLED , 30K hours , No Driver |
| masa | 162/167g (Typ./Max.) |
| uporablja za | Outdoor High Brightness Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 8-bit) , FPC 50 pins |
| napajanje z napetostjo | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maks. ocene | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
