| PartNumber | JJ070IA-18L |
| Znamka | Innolux |
| Velikost | 7.0 |
| Aplikacija | Automotive Display |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 7S2P |
| Vmesnik | LVDS |
| proizvajalec | Innolux |
| velikost zaslona | 7.0 inch |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| površina okvirja (mm) | 155.4 × 94.44 (H×V) |
| svetilnost | 750 cd/m² (Typ.) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 70% NTSC |
| masa | 195±9g |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 8-bit) , 50 pins FPC |
| napajanje z napetostjo | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| maks. ocene | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| ime modela | JJ070IA-18L |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 162.8 × 104.84 (H×V×D) |
| zdravljenje | Antiglare |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| odgovor | 15/10 (Typ.)(Tr/Td) ms |
| način dela | IPS, Normally Black, Transmissive |
| osvetlitev ozadja | 7S2P WLED , 20K hours , No Driver |
| uporablja za | Automotive Display |
| zaslon na dotik | Without |
