| PartNumber | IAQX10N |
| Znamka | IDTech |
| Velikost | 15.0 |
| Aplikacija | NBPC |
| Resolucija | 2048×1536 |
| Sestava | LCM |
| Svetlost | 150 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | IDTech |
| panelni model | IAQX10N |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.0 inch |
| resolucija | 2048(RGB)×1536 , QXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 304.1×228.1 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | |
| svetlost | 150 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 30/30 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFL |
| signalni vmesnik | LVDS (2 ch, 6-bit) |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
