| PartNumber | HSD104IXN1-A01-0299 |
| Znamka | HannStar |
| Velikost | 10.4 |
| Aplikacija | Industrial Automotiv |
| Resolucija | 1024×768 |
| Sestava | CELL , a-Si TFT-LC |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | No |
| Vmesnik | |
| proizvajalec | HannStar |
| velikost zaslona | 10.4 inch |
| število slikovnih pik | 1024(RGB)×768 (XGA) 123PPI |
| aktivna površina (mm) | 211.2 × 158.4 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 0 (cd/m²) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| debelina stekla | 0.50+0.50 mm |
| barvna globina | 262K/16.2M 70% NTSC |
| masa | 100±10g |
| hitrost osveževanja | 60Hz |
| ime modela | HSD104IXN1-A01-0299 |
| vrsto zaslona | CELL , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 220.9 × 168.75 × 1.3 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| način dela | IPS Pro, Normally Black, Transmissive |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| transmisivnost | 4.68% (Typ.)(with Polarizer) |
| osvetlitev ozadja | No B/L |
| uporablja za | Industrial Automotive Display |
| zaslon na dotik | Without |
