| PartNumber | HSD070I651-D00-0299 |
| Znamka | HannStar |
| Velikost | 7.0 |
| Aplikacija | Digital Photo Frame |
| Resolucija | 480×234 |
| Sestava | CELL, a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | Full |
| Osvetlitev ozadja | No |
| Vmesnik | |
| proizvajalec | HannStar |
| ime modela | HSD070I651-D00-0299 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | CELL, a-Si TFT-LCD |
| število slikovnih pik | 480(RGB)×234 76PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 154.08 × 86.58 (H×V) |
| obris (mm) | 164.9 × 100 × 1.69 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 60/60/40/60 (Typ.)(CR≥10) |
| odgovor | 5/20 (Typ.)(Tr/Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| debelina stekla | 0.63+0.63 mm |
| transmisivnost | 9.0% (Typ.)(with Polarizer) |
| barvna globina | Full color |
| osvetlitev ozadja | No B/L |
| masa | 55.3/58.3g (Typ./Max.) |
| uporablja za | Digital Photo Frame Portable DVD Player |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA070MA32BW | CPT | 7.0 | 800×600 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| ED070NA-01N | Innolux | 7.0 | 1024×600 |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| HSD070I651-F20 | HannStar | 7.0 | 480×234 |
| LTA070B511F | TOSHIBA | 7.0 | 800×480 |
