| PartNumber | HSD060FMW1-C00 |
| Znamka | HannStar |
| Velikost | 6.0 |
| Aplikacija | MPH |
| Resolucija | 540×960 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | MIPI |
| znamka plošče | HannStar |
| panelni model | HSD060FMW1-C00 1 Compatible model |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 6.0 inch |
| resolucija | 540(RGB)×960 , qHD |
| način prikaza | IPS Pro, Normally Black, Transmissive |
| aktivno območje | 73.99×131.53 mm |
| oris | 76.58×139.02×0.5 mm |
| površino | Without Polarizer |
| globina stekla | 0.25+0.25 mm |
| transmisivnost | 11.52% (Typ.)(without Polarizer) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| voznik ic | Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| signalni vmesnik | MIPI (2 data lanes) |
| aplikacija | MPH |
