| PartNumber | TFD60W12 |
| Znamka | TOSHIBA |
| Velikost | 6.0 |
| Aplikacija | IA |
| Resolucija | 320×234 |
| Sestava | LCM |
| Svetlost | 280 |
| CR | 80:1 |
| Barve | Full color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Analog |
| znamka plošče | TOSHIBA |
| panelni model | TFD60W12 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 6.0 inch |
| resolucija | 320(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 121.92×89.154 mm |
| oris | 144×109.4 mm |
| površino | |
| svetlost | 280 cd/m² (Typ.) |
| kontrastno razmerje | 80:1 (Typ.) |
| barve zaslona | Full color |
| odzivni čas | 70/40 (Max.)(Tr/Td) |
| vidni kot | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | TFT Specific Analog RGB, 24 pins |
| vhodna napetost | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
| aplikacija | IA |
