| PartNumber | GV101WXB-NZ1-DGP0 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | CELL, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | |
| proizvajalec | BOE |
| ime modela | GV101WXB-NZ1-DGP0 |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | CELL, a-Si TFT-LCD |
| število slikovnih pik | 1280(RGB)×800 (WXGA) 149PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 216.96 × 135.6 (H×V) |
| obris (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Without Polarizer, Hard coating |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 35 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | ADS, Normally Black, Transmissive |
| barvna globina | 16.7M 50% NTSC |
| osvetlitev ozadja | No B/L , With LED Driver |
| masa | - |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| TT101WSQ-N10 | BOE | 10.1 | 1024×600 |
