| PartNumber | G270HAN01.0 |
| Znamka | AUO |
| Velikost | 27.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | G270HAN01.0 |
| velikost plošče | 27.0" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 81PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 597.888(W)×336.312(H) mm |
| odprtina okvirja | 602(W)×340.4(H) mm |
| velikost obrisa | 630(W)×368.2(H) ×23.4(D) mm |
| površino | Antiglare |
| svetlost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | AHVA, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 14 (Typ.)(Tr+Td) |
| barve zaslona | 1.07B 87% NTSC |
| tip svetilke | WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 3.40Kgs (Typ.) |
| aplikacija | Industrial Outdoor High Brightness |
| signalni vmesnik | LVDS , 51 pins Connector |
| vhodna napetost | 12.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HR270WU1-200 | BOE | 27.0 | 1920×1080 |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LM270WR2-SPA1 | LG Display | 27.0 | 3840×2160 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270QAN01.1 | AUO | 27.0 | 3840×2160 |
