| PartNumber | G185XW01 V201 |
| Znamka | AUO |
| Velikost | 18.5 |
| Aplikacija | Industrial |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | G185XW01 V201 |
| velikost plošče | 18.5" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1366(RGB)×768, WXGA, 84PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 409.8(W)×230.4(H) mm |
| odprtina okvirja | 413.4(W)×234.0(H) mm |
| velikost obrisa | 430.4(W)×254.7(H) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 85/85/80/80 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | - |
| odzivni čas | 3.5/1.5 (Typ.)(Tr/Td) |
| barve zaslona | 16.7M 70% NTSC |
| tip svetilke | WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 1.44Kgs (Max.) |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 30 pins Connector |
| vhodna napetost | 5.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
