| PartNumber | G170ETN03.1 |
| Znamka | AUO |
| Velikost | 17.0 |
| Aplikacija | Industrial |
| Resolucija | 1280×1024 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AUO |
| model | G170ETN03.1 |
| velikost diagonale | 17.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×1024 [SXGA] 96PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 337.92(H)×270.336(V) mm |
| obris dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| območje okvirja | 341.7(H)×274.1(V) mm |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | 3.8/1.2 (Typ.)(Tr/Td) |
| vidni kot | 85/85/80/80 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | WLED [9S4P] , 30K hours , W/O Driver |
| utež | 1.27Kgs (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
