| PartNumber | G104X1-L01 |
| Znamka | Innolux |
| Velikost | 10.4 |
| Aplikacija | GM |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 1200:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | CMO |
| panelni model | G104X1-L01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno območje | 210.4×157.8 mm |
| oris | 225.5×176.3×10.67 mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1200:1 (Typ.) |
| barve zaslona | 16.2M (6-bit + FRC), CIE193157% |
| odzivni čas | 14/11 (Typ.)(Tr/Td) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | GM |
