| PartNumber | G101STN01.D |
| Znamka | AUO |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 1024(RGB)×600 (WSVGA) 117PPI |
| aktivna površina (mm) | 222.72 × 125.28 (H×V) |
| površina okvirja (mm) | 226.43 × 128.1 (H×V) |
| svetilnost | 450 cd/m² (Typ.) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10) |
| dober pogled na | - |
| barvna globina | 262K/16.7M 45% NTSC |
| masa | 180g (Typ.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| ime modela | G101STN01.D |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 235 × 143 × 5.2 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| odgovor | 7/9 (Typ.)(Tr/Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
