| PartNumber | G101EAN02.2 |
| Znamka | AUO |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | G101EAN02.2 |
| velikost plošče | 10.1" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1280(RGB)×800, WXGA, 149PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 216.96(W)×135.6(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 227.91(W)×148(H) ×7.75(D) mm |
| površino | Hard coating |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | AHVA, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 29 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 50% NTSC |
| tip svetilke | WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 290g (Max.) |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
