| PartNumber | F-51900NCU-FW-ADN |
| Znamka | OPTREX |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | CSTN-LCD, LCM |
| Svetlost | |
| CR | 25:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel |
| znamka | OPTREX |
| model | F-51900NCU-FW-ADN |
| velikost diagonale | 5.7 inch |
| vrsta | CSTN-LCD, LCM |
| slikovnih pik | 320(RGB)×240 [QVGA] 70PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 115.2(H)×86.4(V) mm |
| obris dim. | 168(H)×111(V) ×7.4(D) mm |
| svetilnost | 120 cd/m² (Typ.) |
| kontrastno razmerje | 25:1 (Typ.) (TM) |
| smer pogleda | 12 o'clock |
| odzivni čas | 300/100 (Typ.)(Tr/Td) |
| vidni kot | - |
| način delovanja | STN, Normally Black, Transmissive |
| podpira barvo | Color |
| Izvor svetlobe | CCFL , 20K hours , W/O Driver |
| utež | 234g (Max.) |
| namenjen za | Industrial |
| hitrost sličic | 70Hz |
| plošča na dotik | Without |
| tip vmesnika | Parallel Data (1ch, 8-bit) |
| napajanje | 3.0/5.0V (Typ.)(VCC) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
