| PartNumber | TM320240EGFWVSWD |
| Znamka | Tianma |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 60 |
| CR | 8:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU |
| znamka plošče | TIANMA |
| panelni model | TM320240EGFWVSWD |
| vrsta plošče | FSTN-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 320×240 , QVGA |
| način prikaza | STN, Black/White (Negative), Transmissive |
| aktivno območje | 115.17×86.37 mm |
| oris | 160×109×14 mm |
| površino | |
| svetlost | 60 cd/m² (Typ.) |
| kontrastno razmerje | 8:1 (Typ.) |
| barve zaslona | Monochrome |
| odzivni čas | 200/160 (Typ.)(Tr/Td) |
| vidni kot | 20/15/20/15 (Typ.)(CR≥2)(L/R/U/D) |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | 8-bit 6080/8080 parallel, 22 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | IA |
