| PartNumber | ET024012DMA |
| Znamka | EDT |
| Velikost | 2.4 |
| Aplikacija | Handheld & PDA |
| Resolucija | 240×320 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 820:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | 8/9/16/18-bit |
| znamka | EDT |
| model | ET024012DMA |
| velikost diagonale | 2.4 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 240(RGB)×320 [QVGA] 166PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 36.72(H)×48.96(V) mm |
| obris dim. | 42.72(H)×60.4(V) mm |
| območje okvirja | 37.72(H)×49.96(V) mm |
| zdravljenje | - |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 820:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 70/70/70/70 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 59% NTSC |
| Izvor svetlobe | WLED [4S1P] , 10K hours , W/O Driver |
| utež | - |
| namenjen za | Handheld & PDA |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | 8/9/16/18-bit 8080 parallel , 35 pins FPC |
| napajanje | 3.0/3.0V (Typ.)(VCI/IOVCC) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
