| PartNumber | DV150X0M-N11 |
| Znamka | BOE |
| Velikost | 15.0 |
| Aplikacija | Digital Signage |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 12S4P |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | DV150X0M-N11 |
| velikost plošče | 15.0" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1024(RGB)×768, XGA, 85PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 304.128(W)×228.096(H) mm |
| odprtina okvirja | 306.5(W)×230.1(H) mm |
| velikost obrisa | 326.5(W)×253.5(H) ×9.7(D) mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | ADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 72% NTSC |
| tip svetilke | 12S4P WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 930g |
| aplikacija | Digital Signage |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
