| PartNumber | DMF-50840NF-FW |
| Znamka | OPTREX |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | FSTN-LCD , LCM |
| Svetlost | |
| CR | 15:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | 1 |
| Vmesnik | |
| znamka plošče | OPTREX |
| velikost plošče | 5.7" |
| resolucija | 320×240, QVGA, 70PPI |
| prikazno območje | 115.2(W)×86.4(H) mm |
| velikost obrisa | 167.1(W)×109(H) ×11(D) mm |
| svetlost | 50 cd/m² (Typ.) |
| vidni kot | 40/50/30/40 (Typ.)(CR≥2) |
| najboljši pogled na | 6 o'clock |
| barve zaslona | Monochrome |
| pogostost | 75Hz |
| utež | 230g (Max.) |
| panelni model | DMF-50840NF-FW |
| vrsta plošče | FSTN-LCD , LCM |
| slikovnih pik | Rectangle |
| odprtina okvirja | 120.0(W)×90.0(H) mm |
| površino | - |
| kontrastno razmerje | 15:1 (Typ.) (TM) |
| način prikaza | STN, Black/White (Negative), Transmissive |
| odzivni čas | 420/210 (Typ.)(Tr/Td) |
| tip svetilke | 1 pcs CCFL , 25K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| EL320.240.36 ET | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| LM057QB1T09 | SHARP | 5.7 | 320×240 |
| LM24P20 | SHARP | 5.7 | 240×128 |
| LQ6NC02 | SHARP | 5.7 | 240×240 |
| TCG057QVLCA-G00 | Kyocera | 5.7 | 320×240 |
| UMSH-8377MD-8T | Other | 5.7 | 640×480 |
