| PartNumber | C084XAN01.0 |
| Znamka | AUO |
| Velikost | 8.4 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×768 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| velikost zaslona | 8.4 inch |
| število slikovnih pik | 1024(RGB)×768 (XGA) 152PPI |
| aktivna površina (mm) | 170.496 × 127.872 (H×V) |
| svetilnost | - |
| vidni kot | - |
| dober pogled na | Symmetry |
| barvna globina | 16.7M |
| masa | - |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 8-bit) , 40 pins Connector |
| maks. ocene | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| ime modela | C084XAN01.0 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | - |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| odgovor | 30 (Max.)(Tr+Td) ms |
| način dela | AHVA, Normally Black, Transmissive |
| osvetlitev ozadja | WLED |
| uporablja za | Automotive Display |
| zaslon na dotik | Without |
