| PartNumber | B140QAN02.2 |
| Znamka | AUO |
| Velikost | 14.0 |
| Aplikacija | Laptop |
| Resolucija | 2560×1440 |
| Sestava | LTPS TFT-LCD, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | AUO |
| panelni model | B140QAN02.2 |
| velikost plošče | 14.0" |
| vrsta plošče | LTPS TFT-LCD, LCM |
| resolucija | 2560(RGB)×1440, Quad-HD, 210PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 309.35(W)×174.01(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 315.05(W)×195.6(H) ×2.4(D) mm |
| površino | Hard coating (3H) |
| svetlost | - |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | AHVA, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M |
| tip svetilke | WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| aplikacija | Laptop |
| signalni vmesnik | eDP (4 Lanes) Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
