| PartNumber | B140QAN01.1 |
| Znamka | AUO |
| Velikost | 14.0 |
| Aplikacija | NBPC |
| Resolucija | 2560×1440 |
| Sestava | LCM |
| Svetlost | 340 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | AUO |
| panelni model | B140QAN01.1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 14.0 inch |
| resolucija | 2560(RGB)×1440 , Quad-HD |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno območje | 309.35×174.01 mm |
| oris | 320.4×205.1×2.6 mm |
| slog oblike | Slim (PCBA Flat, Depth ≤3.2mm) |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 340 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | eDP (4 Lanes), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
