| PartNumber | AV080WSM-NW2 |
| Znamka | BOE |
| Velikost | 8.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×600 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 3S10P |
| Vmesnik | LVDS |
| proizvajalec | BOE |
| ime modela | AV080WSM-NW2 |
| velikost zaslona | 8.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×600 (WSVGA) 148PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 176.64 × 99.36 (H×V) |
| obris (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| površina okvirja (mm) | 180.1 × 103.4 (H×V) |
| zdravljenje | - |
| svetilnost | 600 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | ADS, Normally Black, Transmissive |
| barvna globina | 262K/16.7M 50% NTSC |
| osvetlitev ozadja | 3S10P WLED , 30K hours , No Driver |
| masa | 176/180g (Typ./Max.) |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| napajanje z napetostjo | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
