| PartNumber | AT070WSM-NW2 |
| Znamka | BOE |
| Velikost | 7.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | BOE |
| model | AT070WSM-NW2 |
| velikost diagonale | 7.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 170PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 154.214(H)×85.92(V) mm |
| obris dim. | - |
| svetilnost | - |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | 25 (Typ.)(Tr+Tf) |
| vidni kot | 80/80/60/70 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K/16.7M 50% NTSC |
| Izvor svetlobe | WLED |
| utež | - |
| namenjen za | Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
