| PartNumber | AM-640480GSTMQW-00H-A |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 640×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | 3S7P |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 5.7" |
| resolucija | 640(RGB)×480, VGA, 141PPI |
| prikazno območje | 115.2(W)×86.4(H) mm |
| velikost obrisa | 144(W)×104.6(H) ×12.6(D) mm |
| svetlost | 400 cd/m² (Typ.) |
| vidni kot | 75/75/65/65 (Typ.)(CR≥10) |
| najboljši pogled na | 6 o'clock |
| barve zaslona | 262K 50% NTSC |
| pogostost | 60Hz |
| utež | - |
| panelni model | AM-640480GSTMQW-00H-A |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 118.2(W)×89.4(H) mm |
| površino | Antiglare |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 50 (Typ.)(Tr+Td) |
| tip svetilke | 3S7P WLED , 20K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
