| PartNumber | AM-640480G4TNQW-TA0H |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 640×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 250:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AMPIRE |
| ime modela | AM-640480G4TNQW-TA0H |
| velikost zaslona | 5.7 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 640(RGB)×480 (VGA) 141PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 115.2 × 86.4 (H×V) |
| obris (mm) | 127 × 98.43 × 9.1 (H×V×D) |
| površina okvirja (mm) | 118.0 × 89.2 (H×V) |
| zdravljenje | - |
| svetilnost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 250 : 1 (Typ.) (TM) |
| vidni kot | 70/70/50/50 (Typ.)(CR≥10) |
| odgovor | 50 (Typ.)(Tr+Td) ms |
| dober pogled na | 12 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K 50% NTSC |
| osvetlitev ozadja | WLED , 20K hours , With LED Driver |
| masa | - |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | 4-wire Resistive Touch |
| vrsto signala | LVDS (1 ch, 6-bit) , Connector 20 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
