| PartNumber | AM-640480G2TNQW-A0H |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 640×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 250:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-640480G2TNQW-A0H |
| velikost diagonale | 5.7 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 640(RGB)×480 [VGA] 141PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 115.2(H)×86.4(V) mm |
| obris dim. | 127(H)×98.43(V) ×7.8(D) mm |
| območje okvirja | 118.0(H)×89.2(V) mm |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 250:1 (Typ.) (TM) |
| smer pogleda | 12 o'clock |
| odzivni čas | 50 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/50 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 50% NTSC |
| Izvor svetlobe | WLED , 20K hours , With LED Driver |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 6-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
