| PartNumber | AM-480272-043D |
| Znamka | Other |
| Velikost | 4.3 |
| Aplikacija | CNS |
| Resolucija | 480×272 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | Amson |
| panelni model | AM-480272-043D |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 4.3 inch |
| resolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 95.04×53.856 mm |
| oris | 105.5×67.2×3.2 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | |
| vidni kot | |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 39 pins |
| vhodna napetost | 3.0V (Typ.) |
| aplikacija | CNS |
