| PartNumber | AM-320240LATNQW-00H-F |
| Znamka | AMPIRE |
| Velikost | 3.5 |
| Aplikacija | HHP |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 300:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | AMPIRE |
| panelni model | AM-320240LATNQW-00H-F |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.5 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 70.08×52.56 mm |
| oris | 77.8×64.5×4.7 mm |
| površino | Antiglare |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 300:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 50 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S2PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | HHP |
