| PartNumber | AM-19201200CTZQW-00 |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1920×1200 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | AMPIRE |
| ime modela | AM-19201200CTZQW-00 |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1200 (WUXGA) 225PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 216.576 × 135.36 (H×V) |
| obris (mm) | 244.8 × 155.3 × 7 (H×V×D) |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M 49% NTSC |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| masa | - |
| uporablja za | Industrial Outdoor High Brightness |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -20 ~ 65 °C Operating Temp.: -20 ~ 65 °C |
