| PartNumber | AM-1280800W2TZQW-00H |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 7S4P |
| Vmesnik | LVDS |
| proizvajalec | AMPIRE |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 1280(RGB)×800 (WXGA) 149PPI |
| aktivna površina (mm) | 216.96 × 135.6 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 1000 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 44% NTSC |
| masa | 160g (Max.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 8-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ime modela | AM-1280800W2TZQW-00H |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 231 × 154.4 × 7.9 (H×V×D) |
| zdravljenje | Glare (Haze 0%), Hard coating (3H) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| način dela | ADS, Normally Black, Transmissive |
| osvetlitev ozadja | 7S4P WLED , 50K hours , No Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
