| PartNumber | AM-1280800P4TZQW-T21H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-1280800P4TZQW-T21H |
| velikost diagonale | 7.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×800 [WXGA] 217PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 149.76(H)×93.6(V) mm |
| obris dim. | 174(H)×118(V) ×13.63(D) mm |
| območje okvirja | - |
| zdravljenje | Glare (Haze 0%) |
| svetilnost | 850 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | SFT, Normally Black, Transmissive |
| podpira barvo | 16.7M 50% NTSC |
| Izvor svetlobe | WLED [6S4P] , 50K hours , With LED Driver |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| tip vmesnika | LVDS (1 ch, 8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
