| PartNumber | AM-1280800J4TZQW-T00 |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-1280800J4TZQW-T00 |
| velikost diagonale | 10.1 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×800 [WXGA] 149PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 216.96(H)×135.6(V) mm |
| obris dim. | 231(H)×150(V) ×8.8(D) mm |
| svetilnost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | Normally Black, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED [3S11P] , 15K hours , With LED Driver |
| utež | TBD |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| tip vmesnika | LVDS (1 ch, 8-bit) , 30 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
