| PartNumber | AM-1024768V1TZQW-A0H |
| Znamka | AMPIRE |
| Velikost | 8.4 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| velikost diagonale | 8.4 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×768 [XGA] 152PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 170.8(H)×128.1(V) mm |
| obris dim. | 203(H)×145.5(V) ×8(D) mm |
| območje okvirja | 174.15(H)×131.2(V) mm |
| zdravljenje | - |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED [6S6P] , 50K hours , With LED Driver |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
