| PartNumber | AM-1024768R3TNQW-T00H |
| Znamka | AMPIRE |
| Velikost | 12.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | AMPIRE |
| model | AM-1024768R3TNQW-T00H |
| velikost diagonale | 12.1 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×768 [XGA] 105PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 245.76(H)×184.32(V) mm |
| obris dim. | 279(H)×209(V) ×11.2(D) mm |
| svetilnost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K/16.7M |
| Izvor svetlobe | WLED , 30K hours , With LED Driver |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
