| PartNumber | A050EAT01.0 |
| Znamka | AUO |
| Velikost | 5.0 |
| Aplikacija | Industrial |
| Resolucija | 1280×720 |
| Sestava | a-Si TFT-LCD, Assemb |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | AUO |
| model | A050EAT01.0 |
| velikost diagonale | 5.0 inch |
| vrsta | a-Si TFT-LCD, Assembly |
| slikovnih pik | 1280×720(RGB) [WXGA] 294PPI |
| konfiguracijo | RGB Horizontal Stripe |
| aktivno območje | 110.4(H)×62.1(V) mm |
| obris dim. | 136.38(H)×91.71(V) ×4.86(D) mm |
| svetilnost | 800 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 20/15 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | - |
| podpira barvo | 16.7M 66% NTSC |
| Izvor svetlobe | WLED [7S3P] , W/O Driver |
| utež | 63g (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| tip vmesnika | MIPI (4 data lanes) , 42 pins Connector |
| napajanje | 1.8/3.3V (Typ.)(VDDI/VCI) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
