| PartNumber | WS020ZVM-N30-6KP0 |
| Znamka | BOE |
| Velikost | 2.0 |
| Aplikacija | Wearable Round Displ |
| Resolucija | 640×572 |
| Sestava | LTPS TFT-LCD, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | BOE |
| model | WS020ZVM-N30-6KP0 |
| velikost diagonale | 2.0 inch |
| vrsta | LTPS TFT-LCD, LCM |
| slikovnih pik | 640(RGB)×572 327PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 49.728(H)×44.364(V) mm |
| obris dim. | 52.1(H)×49.8(V) mm |
| svetilnost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | ADS, Normally Black, Transmissive |
| podpira barvo | 16.7M 70% NTSC |
| Izvor svetlobe | WLED [4S1P] , W/O Driver |
| utež | - |
| namenjen za | Wearable Round Display |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| tip vmesnika | MIPI (1 data lane) , 30 pins Connector |
| napajanje | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| okolju | Operating Temperature: -10 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
