| PartNumber | WEO128128BS |
| Znamka | Winstar |
| Velikost | 1.2 |
| Aplikacija | Wearable Round Displ |
| Resolucija | 128×128 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Blue) |
| Osvetlitev ozadja | self |
| Vmesnik | 8-bit |
| znamka | Winstar |
| model | WEO128128BS |
| velikost diagonale | 1.2 inch |
| vrsta | PM-OLED, OLED |
| slikovnih pik | 128×128 108PPI |
| konfiguracijo | Rectangle |
| aktivno območje | 30(H)×30(V) mm |
| obris dim. | 36.98(H)×41.23(V) ×2.25(D) mm |
| smer pogleda | Symmetry |
| odzivni čas | - |
| vidni kot | - |
| način delovanja | - |
| podpira barvo | Mono(Blue) |
| Izvor svetlobe | self |
| utež | - |
| namenjen za | Wearable Round Display |
| hitrost sličic | - |
| plošča na dotik | Without |
| detajl d-ic | COG Built-in SSD1327ZB |
| tip vmesnika | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| napajanje | 3.0V (Typ.) |
| okolju | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
