| PartNumber | WEO012864KL |
| Znamka | Winstar |
| Velikost | 2.7 |
| Aplikacija | Handheld & PDA Instr |
| Resolucija | 128×64 |
| Sestava | OLED , PM-OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Yellow) |
| Osvetlitev ozadja | self |
| Vmesnik | 8-bit |
| proizvajalec | Winstar |
| velikost zaslona | 2.7 inch |
| število slikovnih pik | 128×64 52PPI |
| aktivna površina (mm) | 61.41 × 30.69 (H×V) |
| površina okvirja (mm) | 63.41 × 32.69 (H×V) |
| vidni kot | - |
| dober pogled na | Symmetry |
| barvna globina | Mono(Yellow) |
| masa | - |
| hitrost osveževanja | - |
| seznam gonilnikov ic | Built-in COG SSD1309ZC |
| vrsto signala | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 31 pins FPC |
| napajanje z napetostjo | 3.0V (Typ.) |
| ime modela | WEO012864KL |
| vrsto zaslona | OLED , PM-OLED |
| ureditev | Rectangle |
| obris (mm) | 73 × 41.86 × 2.15 (H×V×D) |
| zdravljenje | - |
| odgovor | - |
| način dela | - |
| osvetlitev ozadja | self |
| uporablja za | Handheld & PDA Instruments & Meters |
| zaslon na dotik | Without |
| A027DN01 VQ | AUO | 2.7 | 320×240 |
| A027DN03 V2 | AUO | 2.7 | 320×240 |
| A027DN03 V8 | AUO | 2.7 | 320×240 |
| A027DN04 V4 | AUO | 2.7 | 320×240 |
| LS027B4DH01 | SHARP | 2.7 | 400×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| OEL9M0065-Y-E | Other | 2.7 | 256×64 |
| RGS27128064YW000 | RiTdisplay | 2.7 | 128×64 |
| TM027CDH12 | Tianma | 2.7 | 320×240 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
